When you have a generational collector, you aim to trace only the part of the object graph that has been allocated recently. To do so, you need to keep a remembered set: a set of old-to-new edges, used as roots when performing a minor collection. A language run-time maintains this set by adding write barriers: little bits of collector code that run when a mutator writes to a field.

Whippet’s nofl space is a block-structured space that is appropriate for use as an old generation or as part of a sticky-mark-bit generational collector. It used to have a card-marking write barrier; see my article diving into V8’s new write barrier, for more background.

Unfortunately, when running whiffle benchmarks, I was seeing no improvement for generational configurations relative to whole-heap collection. Generational collection was doing fine in my tiny microbenchmarks that are part of Whippet itself, but when translated to larger programs (that aren’t yet proper macrobenchmarks), it was a lose.

I had planned on doing some serious tracing and instrumentation to figure out what was happening, and thereby correct the problem. I still plan on doing this, but instead for this issue I used the old noggin technique instead: just, you know, thinking about the thing, eventually concluding that unconditional card-marking barriers are inappropriate for sticky-mark-bit collectors. As I mentioned in the earlier article:

An unconditional card-marking barrier applies to stores to slots in all objects, not just those in oldspace; a store to a new object will mark a card, but that card may contain old objects which would then be re-scanned. Or consider a store to an old object in a more dense part of oldspace; scanning the card may incur more work than needed. It could also be that Whippet is being too aggressive at re-using blocks for new allocations, where it should be limiting itself to blocks that are very sparsely populated with old objects.

That’s three problems. The second is well-known. But the first and last are specific to sticky-mark-bit collectors, where pages mix old and new objects.

a precise field-logging write barrier

Back in 2019, Steve Blackburn’s paper Design and Analysis of Field-Logging Write Barriers took a look at the state of the art in precise barriers that record not regions of memory that have been updated, but the precise edges (fields) that were written to. He ends up re-using this work later in the 2022 LXR paper (see §3.4), where the write barrier is used for deferred reference counting and a snapshot-at-the-beginning (SATB) barrier for concurrent marking. All in all field-logging seems like an interesting strategy. Relative to card-marking, work during the pause is much less: you have a precise buffer of all fields that were written to, and you just iterate that, instead of iterating objects. Field-logging does impose some mutator cost, but perhaps the payoff is worth it.

To log each old-to-new edge precisely once, you need a bit per field indicating whether the field is logged already. Blackburn’s 2019 write barrier paper used bits in the object header, if the object was small enough, and otherwise bits before the object start. This requires some cooperation between the collector, the compiler, and the run-time that I wasn’t ready to pay for. The 2022 LXR paper was a bit vague on this topic, saying just that it used “a side table”.

In Whippet’s nofl space, we have a side table already, used for a number of purposes:

1. Mark bits.

2. Iterability / interior pointers: is there an object at a given address? If so, it will have a recognizable bit pattern.

3. End of object, to be able to sweep without inspecting the object itself

4. Pinning, allowing a mutator to prevent an object from being evacuated, for example because a hash code was computed from its address

5. A hack to allow fully-conservative tracing to identify ephemerons at trace-time; this re-uses the pinning bit, since in practice such configurations never evacuate

6. Bump-pointer allocation into holes: the mark byte table serves the purpose of Immix’s line mark byte table, but at finer granularity. Because of this though, it is swept lazily rather than eagerly.

7. Generations. Young objects have a bit set that is cleared when they are promoted.

Well. Why not add another thing? The nofl space’s granule size is two words, so we can use two bits of the byte for field logging bits. If there is a write to a field, a barrier would first check that the object being written to is old, and then check the log bit for the field being written. The old check will be to a byte that is nearby or possibly the same as the one to check the field logging bit. If the bit is unsert, we call out to a slow path to actually record the field.

preliminary results

I disassembled the fast path as compiled by GCC and got something like this on x86-64, in AT&T syntax, for the young-generation test:

mov    %rax,%rdx
and    $0xffffffffffc00000,%rdx
shr    $0x4,%rax
and    $0x3ffff,%eax
or     %rdx,%rax
testb  $0xe,(%rax)

The first five instructions compute the location of the mark byte, from the address of the object (which is known to be in the nofl space). If it has any of the bits in 0xe set, then it’s in the old generation.

Then to test a field logging bit it’s a similar set of instructions. In one of my tests the data type looks like this:

struct Node {
  uintptr_t tag;
  struct Node *left;
  struct Node *right;
  int i, j;
};

Writing the left field will be in the same granule as the object itself, so we can just test the byte we fetched for the logging bit directly with testb against $0x80. For right, we should be able to know it’s in the same slab (aligned 4 MB region) and just add to the previously computed byte address, but the C compiler doesn’t know that right now and so recomputes. This would work better in a JIT. Anyway I think these bit-swizzling operations are just lost in the flow of memory accesses.

For the general case where you don’t statically know the offset of the field in the object, you have to compute which bit in the byte to test:

mov    %r13,%rcx
mov    $0x40,%eax
shr    $0x3,%rcx
and    $0x1,%ecx
shl    %cl,%eax
test   %al,%dil

Is it good? Well, it improves things for my whiffle benchmarks, relative to the card-marking barrier, seeing a 1.05×-1.5× speedup across a range of benchmarks. I suspect the main advantage is in avoiding the “unconditional” part of card marking, where a write to a new object could cause old objects to be added to the remembered set. There are still quite a few whiffle configurations in which the whole-heap collector outperforms the sticky-mark-bit generational collector, though; I hope to understand this a bit more by building a more classic semi-space nursery, and comparing performance to that.

Implementation links: the barrier fast-path, the slow path, and the sequential store buffers. (At some point I need to make it so that allocating edge buffers in the field set causes the nofl space to page out a corresponding amount of memory, so as to be honest when comparing GC performance at a fixed heap size.)

Until next time, onwards and upwards!

Takes a list and splits it in order into smaller lists such that each list contains one pred. If there are no pred, that’s fine, DTRT silently i.e. make a one-element list containing the whole list.

(define (vowel? l) ((as-list (c member l)) "aeiou"))

(define (chunk-by pred lis) (list lis))

(define (chunk-by pred lis)
  (receive (hd tl)
      (split-at lis (add1 (require number? (list-index pred lis))))
    (cons hd (chunk-by pred (require (c any pred) tl)))))

(chunk-by vowel? (string->list "somejunk"))

⇒ ((#\s #\o) (#\m #\e) (#\j #\u #\n #\k))

• brev

Hey all, I had a fun bug this week and want to share it with you.

numbers and representations

First, though, some background. Guile’s numeric operations are defined over the complex numbers, not over e.g. a finite field of integers. This is generally great when writing an algorithm, because you don’t have to think about how the computer will actually represent the numbers you are working on.

In practice, Guile will represent a small exact integer as a fixnum, which is a machine word with a low-bit tag. If an integer doesn’t fit in a word (minus space for the tag), it is represented as a heap-allocated bignum. But sometimes the compiler can realize that e.g. the operands to a specific bitwise-and operation are within (say) the 64-bit range of unsigned integers, and so therefore we can use unboxed operations instead of the more generic functions that do run-time dispatch on the operand types, and which might perform heap allocation.

Unboxing is important for speed. It’s also tricky: under what circumstances can we do it? In the example above, there is information that flows from defs to uses: the operands of logand are known to be exact integers in a certain range and the operation itself is closed over its domain, so we can unbox.

But there is another case in which we can unbox, in which information flows backwards, from uses to defs: if we see (logand n #xff), we know:

• the result will be in [0, 255]

• that n will be an exact integer (or an exception will be thrown)

• we are only interested in a subset of n‘s bits.

Together, these observations let us transform the more general logand to an unboxed operation, having first truncated n to a u64. And actually, the information can flow from use to def: if we know that n will be an exact integer but don’t know its range, we can transform the potentially heap-allocating computation that produces n to instead truncate its result to the u64 range where it is defined, instead of just truncating at the use; and potentially this information could travel farther up the dominator tree, to inputs of the operation that defines n, their inputs, and so on.

needed-bits: the |0 of scheme

Let’s say we have a numerical operation that produces an exact integer, but we don’t know the range. We could truncate the result to a u64 and use unboxed operations, if and only if only u64 bits are used. So we need to compute, for each variable in a program, what bits are needed from it.

I think this is generally known a needed-bits analysis, though both Google and my textbooks are failing me at the moment; perhaps this is because dynamic languages and flow analysis don’t get so much attention these days. Anyway, the analysis can be local (within a basic block), global (all blocks in a function), or interprocedural (larger than a function). Guile’s is global. Each CPS/SSA variable in the function starts as needing 0 bits. We then compute the fixpoint of visiting each term in the function; if a term causes a variable to flow out of the function, for example via return or call, the variable is recorded as needing all bits, as is also the case if the variable is an operand to some primcall that doesn’t have a specific needed-bits analyser.

Currently, only logand has a needed-bits analyser, and this is because sometimes you want to do modular arithmetic, for example in a hash function. Consider Bon Jenkins’ lookup3 string hash function:

#define rot(x,k) (((x)<<(k)) | ((x)>>(32-(k))))
#define mix(a,b,c) \
{ \
  a -= c;  a ^= rot(c, 4);  c += b; \
  b -= a;  b ^= rot(a, 6);  a += c; \
  c -= b;  c ^= rot(b, 8);  b += a; \
  a -= c;  a ^= rot(c,16);  c += b; \
  b -= a;  b ^= rot(a,19);  a += c; \
  c -= b;  c ^= rot(b, 4);  b += a; \
}
...

If we transcribe this to Scheme, we get something like:

(define (jenkins-lookup3-hashword2 str)
  (define (u32 x) (logand x #xffffFFFF))
  (define (shl x n) (u32 (ash x n)))
  (define (shr x n) (ash x (- n)))
  (define (rot x n) (logior (shl x n) (shr x (- 32 n))))
  (define (add x y) (u32 (+ x y)))
  (define (sub x y) (u32 (- x y)))
  (define (xor x y) (logxor x y))

  (define (mix a b c)
    (let* ((a (sub a c)) (a (xor a (rot c 4)))  (c (add c b))
           (b (sub b a)) (b (xor b (rot a 6)))  (a (add a c))
           (c (sub c b)) (c (xor c (rot b 8)))  (b (add b a))
           ...)
      ...))

  ...

These u32 calls are like the JavaScript |0 idiom, to tell the compiler that we really just want the low 32 bits of the number, as an integer. Guile’s compiler will propagate that information down to uses of the defined values but also back up the dominator tree, resulting in unboxed arithmetic for all of these operations.

(When writing this, I got all the way here and then realized I had already written quite a bit about this, almost a decade ago ago. Oh well, consider this your lucky day, you get two scoops of prose!)

the bug

All that was just prelude. So I said that needed-bits is a fixed-point flow analysis problem. In this case, I want to compute, for each variable, what bits are needed for its definition. Because of loops, we need to keep iterating until we have found the fixed point. We use a worklist to represent the conts we need to visit.

Visiting a cont may cause the program to require more bits from the variables that cont uses. Consider:

(define-significant-bits-handler
    ((logand/immediate label types out res) param a)
  (let ((sigbits (sigbits-intersect
                   (inferred-sigbits types label a)
                   param
                   (sigbits-ref out res))))
    (intmap-add out a sigbits sigbits-union)))

This is the sigbits (needed-bits) handler for logand when one of its operands (param) is a constant and the other (a) is variable. It adds an entry for a to the analysis out, which is an intmap from variable to a bitmask of needed bits, or #f for all bits. If a already has some computed sigbits, we add to that set via sigbits-union. The interesting point comes in the sigbits-intersect call: the bits that we will need from a are first the bits that we infer a to have, by forward type-and-range analysis; intersected with the bits from the immediate param; intersected with the needed bits from the result value res.

If the intmap-add call is idempotent—i.e., out already contains sigbits for a—then out is returned as-is. So we can check for a fixed-point by comparing out with the resulting analysis, via eq?. If they are not equal, we need to add the cont that defines a to the worklist.

The bug? The bug was that we were not enqueuing the def of a, but rather the predecessors of label. This works when there are no cycles, provided we visit the worklist in post-order; and regardless, it works for many other analyses in Guile where we compute, for each labelled cont (basic block), some set of facts about all other labels or about all other variables. In that case, enqueuing a predecessor on the worklist will cause all nodes up and to including the variable’s definition to be visited, because each step adds more information (relative to the analysis computed on the previous visit). But it doesn’t work for this case, because we aren’t computing a per-label analysis.

The solution was to rewrite that particular fixed-point to enqueue labels that define a variable (possibly multiple defs, because of joins and loop back-edges), instead of just the predecessors of the use.

Et voilà ! If you got this far, bravo. Type at y’all again soon!

Greetings, gentle readers. Today, an update on recent progress in the Whippet embeddable garbage collection library.

feature-completeness

When I started working on Whippet, two and a half years ago already, I was aiming to make a new garbage collector for Guile. In the beginning I was just focussing on proving that it would be advantageous to switch, and also learning how to write a GC. I put off features like ephemerons and heap resizing until I was satisfied with the basics.

Well now is the time: with recent development, Whippet is finally feature-complete! Huzzah! Now it’s time to actually work on getting it into Guile. (I have some performance noodling to do before then, adding tracing support, and of course I have lots of ideas for different collectors to build, but I don’t have any missing features at the current time.)

heap resizing

When you benchmark a garbage collector (or a program with garbage collection), you generally want to fix the heap size. GC overhead goes down with more memory, generally speaking, so you don’t want to compare one collector at one size to another collector at another size.

(Unfortunately, many (most?) benchmarks of dynamic language run-times and the programs that run on them fall into this trap. Imagine you are benchmarking a program before and after a change. Automatic heap sizing is on. Before your change the heap size is 200 MB, but after it is 180 MB. The benchmark shows the change to regress performance. But did it really? It could be that at the same heap size, the change improved performance. You won’t know unless you fix the heap size.)

Anyway, Whippet now has an implementation of MemBalancer. After every GC, we measure the live size of the heap, and compute a new GC speed, as a constant factor to live heap size. Every second, in a background thread, we observe the global allocation rate. The heap size is then the live data size plus the square root of the live data size times a factor. The factor has two components. One is constant, the expansiveness of the heap: the higher it is, the more room the program has. The other depends on the program, and is computed as the square root of the ratio of allocation speed to collection speed.

With MemBalancer, the heap ends up getting resized at every GC, and via the heartbeat thread. During the GC it’s easy because it’s within the pause; no mutators are running. From the heartbeat thread, mutators are active: taking the heap lock prevents concurrent resizes, but mutators are still consuming empty blocks and producing full blocks. This works out fine in the same way that concurrent mutators is fine: shrinking takes blocks from the empty list one by one, atomically, and returns them to the OS. Expanding might reclaim paged-out blocks, or allocate new slabs of blocks.

However, even with some exponentially weighted averaging on the speed observations, I have a hard time understanding whether the algorithm is overall a good thing. I like the heartbeat thread, as it can reduce memory use of idle processes. The general square-root idea sounds nice enough. But adjusting the heap size at every GC feels like giving control of your stereo’s volume knob to a hyperactive squirrel.

Furthermore, the graphs in the MemBalancer paper are not clear to me: the paper claims more optimal memory use even in a single-heap configuration, but the x axis of the graphs is “average heap size”, which I understand to mean that maximum heap size could be higher than V8’s maximum heap size, taking into account more frequent heap size adjustments. Also, some measurement of total time would have been welcome, in addition to the “garbage collection time” on the paper’s y axis; there are cases where less pause time doesn’t necessarily correlate to better total times.

deferred page-out

Motivated by MemBalancer’s jittery squirrel, I implemented a little queue for use in paging blocks in and out, for the mmc and pcc collectors: blocks are quarantined for a second or two before being returned to the OS via madvise(MADV_DONTNEED). That way if you release a page and then need to reacquire it again, you can do so without bothering the kernel or other threads. Does it matter? It seems to improve things marginally and conventional wisdom says to not mess with the page table too much, but who knows.

mmc rename

Relatedly, Whippet used to be three things: the project itself, consisting of an API and a collection of collectors; one specific collector; and one specific space within that collector. Last time I mentioned that I renamed the whippet space to the nofl space. Now I finally got around to renaming what was the whippet collector as well: it is now the mostly-marking collector, or mmc. Be it known!

Also as a service note, I removed the “serial copying collector” (scc). It had the same performance as the parallel copying collector with parallelism=1, and pcc can be compiled with GC_PARALLEL=0 to explicitly choose the simpler serial grey-object worklist.

per-object pinning

The nofl space has always supported pinned objects, but it was never exposed in the API. Now it is!

Of course, collectors with always-copying spaces won’t be able to pin objects. If we want to support use of these collectors with embedders that require pinning, perhaps because of conservative root scanning, we’d need to switch to some kind of mostly-copying algorithm.

safepoints without allocation

Another missing feature was a safepoint API. It hasn’t been needed up to now because my benchmarks all allocate, but for programs that have long (tens of microseconds maybe) active periods without allocation, you want to be able to stop them without waiting too long. Well we have that exposed in the API now.

removed ragged stop

Following on my article on ragged stops, I removed ragged-stop marking from mmc, for a nice net 180 line reduction in some gnarly code. Speed seems to be similar.

next up: tracing

And with that, I’m relieved to move on to the next phase of Whippet development. Thanks again to NLnet for their support of this work. Next up, adding fine-grained tracing, so that I can noodle a bit on performance. Happy allocating!

Should your garbage collector be precise or conservative? The prevailing wisdom is that precise is always better. Conservative GC can retain more objects than strictly necessary, making GC slow: GC has to more frequently, and it has to trace a larger heap on each collection. However the calculus is not as straightforward as most people think, and indeed there are some reasons to expect that conservative root-finding can result in faster systems.

(I have made / relayed some of these arguments before but I feel like a dedicated article can make a contribution here.)

problem precision

Let us assume that by conservative GC we mean conservative root-finding, in which the collector assumes that any integer on the stack that happens to be a heap address indicates a reference on the object containing that address. The address doesn’t have to be at the start of the object. Assume that objects on the heap are traced precisely; contrast to BDW-GC which generally traces both the stack and the heap conservatively. Assume a collector that will pin referents of conservative roots, but in which objects not referred to by a conservative root can be moved, as in Conservative Immix or Whippet’s stack-conservative-mmc collector.

With that out of the way, let’s look at some reasons why conservative GC might be faster than precise GC.

smaller lifetimes

A compiler that does precise root-finding will typically output a side-table indicating which slots in a stack frame hold references to heap objects. These lifetimes aren’t always precise, in the sense that although they precisely enumerate heap references, those heap references might actually not be used in the continuation of the stack frame. When GC occurs, it might mark more objects as live than are actually live, which is the imputed disadvantage of conservative collectors.

This is most obviously the case when you need to explicitly register roots with some kind of handle API: the handle will typically be kept live until the scope ends, but that might be an overapproximation of lifetime. A compiler that can assume conservative stack scanning may well exhibit more precision than it would if it needed to emit stack maps.

no run-time overhead

For generated code, stack maps are great. But if a compiler needs to call out to C++ or something, it needs to precisely track roots in a run-time data structure. This is overhead, and conservative collectors avoid it.

smaller stack frames

A compiler may partition spill space on a stack into a part that contains pointers to the heap and a part containing numbers or other unboxed data. This may lead to larger stack sizes than if you could just re-use a slot for two purposes, if the lifetimes don’t overlap. A similar concern applies for compilers that partition registers.

no stack maps

The need to emit stack maps is annoying for a compiler and makes binaries bigger. Of course it’s necessary for precise roots. But then there is additional overhead when tracing the stack: for each frame on the stack, you need to look up the stack map for the return continuation, which takes time. It may be faster to just test if words on the stack might be pointers to the heap.

unconstrained compiler

Having to make stack maps is a constraint imposed on the compiler. Maybe if you don’t need them, the compiler could do a better job, or you could use a different compiler entirely. A conservative compiler can sometimes have better codegen, for example by the use of interior pointers.

anecdotal evidence

The Conservative Immix paper shows that conservative stack scanning can beat precise scanning in some cases. I have reproduced these results with parallel-stack-conservative-mmc compared to parallel-mmc. It’s small—maybe a percent—but it was a surprising result to me and I thought others might want to know.

Also, Apple’s JavaScriptCore uses conservative stack scanning, and V8 is looking at switching to it. Funny, right?

conclusion

When it comes to designing a system with GC, don’t count out conservative stack scanning; the tradeoffs don’t obviously go one way or the other, and conservative scanning might be the right engineering choice for your system.

Many years ago I read one of those Cliff Click “here’s what I learned” articles in which he was giving advice about garbage collector design, and one of the recommendations was that at a GC pause, running mutator threads should cooperate with the collector by identifying roots from their own stacks. You can read a similar assertion in their VEE2005 paper, The Pauseless GC Algorithm, though this wasn’t the source of the information.

One motivation for the idea was locality: a thread’s stack is already local to a thread. Then specifically in the context of a pauseless collector, you need to avoid races between the collector and the mutator for a thread’s stack, and having the thread visit its own stack neatly handles this problem.

However, I am not so interested any more in (so-called) pauseless collectors; though I have not measured myself, I am convinced enough by the arguments in the Distilling the real costs of production garbage collectors paper, which finds that state of the art pause-minimizing collectors actually increase both average and p99 latency, relative to a well-engineered collector with a pause phase. So, the racing argument is not so relevant to me, because a pause is happening anyway.

There was one more argument that I thought was interesting, which was that having threads visit their own stacks is a kind of cheap parallelism: the mutator threads are already there, they might as well do some work; it could be that it saves time, if other threads haven’t seen the safepoint yet. Mutators exhibit a ragged stop, in the sense that there is no clean cutoff time at which all mutators stop simultaneously, only a time after which no more mutators are running.

Visiting roots during a ragged stop introduces concurrency between the mutator and the collector, which is not exactly free; notably, it prevents objects marked while mutators are running from being evacuated. Still, it could be worth it in some cases.

Or so I thought! Let’s try to look at the problem analytically. Consider that you have a system with N processors, a stop-the-world GC with N tracing threads, and M mutator threads. Let’s assume that we want to minimize GC latency, as defined by the time between GC is triggered and the time that mutators resume. There will be one triggering thread that causes GC to begin, and then M–1 remote threads that need to reach a safepoint before the GC pause can begin.

The total amount of work that needs to be done during GC can be broken down into roots_i, the time needed to visit roots for mutator i, and then graph, the time to trace the transitive closure of live objects. We want to know whether it’s better to perform roots_i during the ragged stop or in the GC pause itself.

Let’s first look to the case where M is 1 (just one mutator thread). If we visit roots before the pause, we have

Which is to say, thread 0 triggers GC, visits its own roots, then enters the pause in which the whole graph is traced by all workers with maximum parallelism. It may be that graph tracing doesn’t fully parallelize, for example if the graph has a long singly-linked list, but the parallelism with be maximal within the pause as there are N workers tracing the graph.

If instead we visit roots within the pause, we have:

This is strictly better than the ragged-visit latency.

If we have two threads, then we will need to add in some delay, corresponding to the time it takes for remote threads to reach a safepoint. Let’s assume that there is a maximum period (in terms of instructions) at which a mutator will check for safepoints. In that case the worst-case delay will be a constant, and we add it on to the latency. Let us assume also there are more than two threads available. The marking-roots-during-the-pause case it’s easiest to analyze:

In this case, a ragged visit could win: while the triggering thread is waiting for the remote thread to stop, it could perform roots₀, moving the work out of the pause, reducing pause time, and reducing latency, for free.

However, we only have this win if the root-visiting time is smaller than the safepoint delay; otherwise we are just prolonging the pause. Thing is, you don’t know in general. If indeed the root-visiting time is short, relative to the delay, we can assume the roots elements of our equation are 0, and so the choice to mark during ragged stop doesn’t matter at all! If we assume instead that root-visiting time is long, then it is suboptimally parallelised: under-parallelised if we have more than M cores, oversubscribed if M is greater than N, and needlessly serializing before the pause while it waits for the last mutator to finish marking its roots. What’s worse, root-visiting actually slows down delay, because the oversubscribed threads compete with visitation for CPU time.

So in summary, I plan to switch away from doing GC work during the ragged stop. It is complexity that doesn’t pay. Onwards and upwards!
